Zero-Error Shop Drawings.
Maximize Your Shop's Tonnage.
SMY3 Engineering provides premier AISC & NISD compliant structural steel detailing packages designed exclusively for US fabricators. Eliminate field reworks, optimize your CNC workflows, and scale your annual capacity without adding fixed overhead.
Capabilities Overview
Detailing Specialties Built for the US Market
Highly detailed, AISC-compliant production and erection packages. We produce clean anchor rod plans, framing layouts, section elevations, piece-mark shop details, and complete hardware lists mapped explicitly to your shop’s preferred assembly workflows.
Comprehensive solutions for complex secondary steel applications. Expert detailing for pan or grating stairs, industrial platform assemblies, OSHA-compliant handrails, vertical egress ladders, safety gates, and custom architectural weldments.
Intelligent 3D structural modeling utilizing the automated intelligence of the SDS2 engine. We configure site connection formulas natively inside the model, allowing for optimized sub-material detailing and adaptive structural geometry coordination.
Advanced multi-material detailing utilizing modern Tekla software stacks. We build robust, constructible LOD 400 models containing absolute geometric fidelity, providing reliable single-source-of-truth project data for major industrial or commercial infrastructure.
Full cross-trade spatial coordination and clash resolution. By merging detailing models directly with architectural plans, foundation concrete grids, and complex mechanical/MEP layouts, we locate and resolve interference errors digitally before fabrication.
Generating seamless, machine-readable automated exports directly from our detailing models. We supply flawless, checked DSTV files for structural drill lines/sawing systems, plate DXF contours for plasma cutting, and high-fidelity XML/KSS data sets.
Operational Alignment
Eliminating the Pain Points of US Fabricators
Our dedicated Project Managers operate within your local US time zone. We draft proactive, clear RFIs that keep your engineering approval workflows moving fast.
We map our models to your precise shop parameters—matching your specific bolt preferences, equipment setups, weld practices, and preferred paint profiles.
Bid confidently on complex 5,000-ton projects. SMY3 acts as your scalable engineering pool, helping you navigate domestic detailer talent shortages.
